Parts
- Winberg Billet Crankshaft for Coyote Stock Stroke 3.650 2.086 Stock Rod Journals 2.656 Stock Main Journals Counterweight Clearance for 5.850 or Longer Rod Balanced to 1700 Bob Weight In stock and Ready to Ship
NOS sandwich-style plate systems are designed to bolt between the upper and lower intake sections on Holley Hi-Ram LS manifolds. Our dry nitrous systems give you everything you need including 2 NOS Pro-Race nitrous solenoids, brackets, hoses, jetting, and hardware, along with your choice of nitrous bottle. At the center of this system is our machined billet 6061-T6 aluminum plate laser engraved with NOS logo, then anodized for great looks and excellent corrosion protection. Our 1-piece plate features machined passages that precisely spray into the center of each cylinder. Plate includes jetting for up to 250 horsepower but is capable of supporting 1000+ horsepower. The plate is made from billet aluminum with passages machined directly into the plate so there is no need to worry about spray bars breaking or spinning.
- This dry single stage plate system sandwiches between the bottom base and top plate on Holley Hi-Ram intake manifolds
- Designed specifically for optimum nitrous distribution on LS-based engines
- Sprays nitrous directly into each cylinder runner for proper nitrous distribution
- Plate features machined 0.103” passage that feeds (8) 0.040” openings per intake runner
- Plate is made from billet 6061-T6 aluminum and has laser etched NOS logo
- Plate is anodized black or clear for corrosion resistance and high quality appearance
- System utilizes two NOS Pro-Race nitrous solenoids
- Includes jetting for 50, 100, 150, 200, and 250 horsepower configurations
- Supports up to 1000+ horsepower (jets purchased separately)
- Includes Plate, Gasket, Hardware, Jet Holders, Solenoids, Brackets, Hose, Fittings, and Jetting for up to 250 horsepower
- Systems available with 10 LB
- The “BlackSheep” camshaft is back in stock!!! The baddest hydraulic roller ls camshaft is here and They don’t last long so get them before they are gone.We know some of you don’t want to go this extreme so we have created the baby black sheep aka “Lamb Cam” just for stock bottom end 5.3 and 6.0 boosted applications which is perfect for your boosted ls swap projects! If you want your LS to sound like a tractor or you Grandpa's Dump Truck then this is not the camshaft for you!1000hp to over 2000hp this camshaft will have you covered...Lift is .650 with a 1.7 rockerdegree to a 112 intake centerline
- Oil Pan, Steel, Clear Zinc, Dart LS Next Gen 3 Skirted Block, Early/Swap F-Body Race Baffled, Spin-On Oil Filter Adapter that Accepts 22mm thread Dart LS Next Gen 3 skirted engine blocks. Oil pan includes a spin-on oil filter adapter MOR-22463 and is designed to be used with a 1998-2002 F body dipstick and tube GM numbers 12628771 and 12551581 Moroso 24152 Pickup Tube for 20152 Oil Pan not included Steel, Wet Sump, 7 Quart Capacity, 6" Deep Early F-Body/Swap Engine Application: Dart LS Next Gen 3 Skirted Block Fits: ’67-’92, ’10-’15 Camaro, ’68-’78 Nova, ’65-’72 Chevelle, ’53-’96 Corvette, ’78-’88 G-Body, and GM S10/S15 Two Wheel Blazer/Truck, Can also be used in additional applications; check dimensions
- Clears a 4.25" stroke and has a 7 Quart Capacity
- Three trap door assembly and removable windage tray for improved oil control
- Fabricated steel with clear zinc finish
- Includes billet aluminum 22mm spin-on filter mount with 1/4" NPT sensor port
- Compatible with LS car application dipstick
FORD COYOTE SWAP OIL PAN KIT
1979-2004 Mustang 5.0L Coyote engine swap. Fits Gen 1 and Gen 2 Coyote engines 2011-2017 model yearsHolley's new Gen1/Gen2 Coyote oil pan makes your Fox body Mustang swap easier. The oil pan design maintains the oil capacity of stock Mustang Coyote oil pan (8 qt. nominal) to ensure adequate oil supply in all street performance and factory-stock type racing applications. The new design installs using stock Coyote engine gasket/baffle assembly to provide factory-like sealing and baffling/windage characteristics. A proprietary design pick-up tube/O-ring and lower sump baffle plate are included. The 302-50 comes equipped with -10 O-ring boss (ORB) port bung at front of pan for easy connection of turbo drain plumbing (fitting and/or plug is user-supplied as needed). The new low-profile front pan geometry permits Coyote engine installation on stock 1984-2004 Mustang K-members (1984-1995 K-members require the use of specific proprietary design Hooker Blackheart engine mounting brackets) and specific aftermarket K-members from AJE, Team Z, Maximum Motorsports, and UPR for 1979-2004 Mustangs. Application fitment is compatible with Hooker Blackheart and other brand Coyote swap headers for 1979-2004 Mustangs. The steel construction is hand-welded for strength, longevity and good looks. The zinc plated finish provides corrosion resistance on the inside and outside of the pan.
- Low-profile front pan geometry permits Coyote engine installation on stock 1984-2004 Mustang K-members (1984-1995 K-members require the use of specific proprietary design Hooker Blackheart engine mounting brackets).
- Also fits specific aftermarket K-members from AJE, Team Z, Maximum Motorsports, and UPR.
- Maintains oil capacity of stock Mustang Coyote oil pan (8 qt. nominal) to ensure adequate oil supply in all street performance and factory-stock type racing applications.
- Installs using stock Coyote engine gasket/baffle assembly to provide factory-like sealing and baffling/windage characteristics.
- The design includes a bung on the left side of the sump for the stock Mustang Coyote oil level sensor.
- Proprietary design pick-up tube/O-ring and lower sump baffle plate are included.
- Equipped with -10 O-ring boss (ORB) port bung at front of pan for easy connection of turbo drain plumbing (fitting and/or plug is user-supplied as needed).
- 100% quality hand-welded construction for strength, longevity and good looks.
- Zinc plated finish provides corrosion resistance on the inside and outside of the pan.
- Fitment compatible with Hooker Blackheart and other brand Coyote swap headers for 1979-2004 Mustangs.
- Oil pan fits 2011-2017 Coyote engines
- Sale!Callies Magnum
- Premium Ultra Case Heat Treated SAE 4340 Steel
- New Design 8 Counter Weight Forging
- Main Journal Dia. 2.749″ 351 Cleveland
- Rod Journal 2.100″
- Rod Length 6.200″
- Stroke 4.000″
- Enhanced rod oiling through the use of Main Bearing Oil Hole Lead-ins
- Gun Drilled Mains
- All Rod Journals Lightened
- TKM Custom Coyote Lift PlatePowder Coated BlackTKM Laser EtchedWill not clear di injector rail boltsMade in House at TKM and Hand Welded by "The" Kevin Mullins
- Sale!
Gen4 LS Timing Cover
Includes:Gen 4 Timing Cover Powder Coated Black with TKM Laser Etched, CNC to clear double roller timing chain set up, timing cover only!
Not for use on LS7 or LS3 Dry Sump Long Snout Cranks - ARP main stud kits help eliminate main cap walk/fretting and protect the threads in your engine block. They include studs made from 8740 chromoly steel and heat-treated in-house to 190,000 psi tensile-strength rating. The precision J-form threads are rolled after heat-treat for much stronger threads than the competition. Kits come complete with hardened parallel-ground washers and high-quality nuts. Add confidence in the strength of your engine build with the ARP main stud kit designed for your application
- The TKM Bigstick is rowdy! The perfect n/a camshaft for the ls series Lift is .625 with a 1.7 rocker Degree to a 109 intake centerline We also offer spring packages in stock Give us a call or email if there are any question about if this camshaft is right for your combo
- The Lamb camshaft is the little brother of the "Black sheep" Don't let the name fool you!!!! This little camshaft will help you meet your goal with the right combo Designed for the 4.8/5.3/6.0 Lift is .615 with a 1.7 rocker degree to a 112 intake centerline We also offer spring packages in stock Give us a call or email if there are any question about if this camshaft is right for your combo
